Fuego Foundry Supplies · Alberton, Gauteng · Since 2015
Dry vibratablesilica liningsfor inductionfurnaces.
The HF range, mixed to grade at our Alberton works, with Rodacor and Rodamit specialist grades and the raw materials behind them. Supplying South African foundries and melt shops since 2015.
Your floor
Reline
Old lining out. Former in. The dry mix goes in around it and is vibrated down, bag by bag.
First firing
The controlled first heat sinters the face against the former. Behind it, the grain stays loose.
Charge
Scrap in.
Melt
The coil does the work. The lining holds it.
Tap
Furnace over, ladle full.
Next heat
Back upright. The lining is intact, and ready to go again.
Stylised. Your process, in section. The lining is the part in orange.
What we supply
The range.
Three families. Data sheets on request; grade selection guidance with every quote.
Dry vibratable silica linings for crucible induction furnaces melting iron and steel. Made in Alberton, supplied dry and ready to use. Grade selected with you against metal and working temperature.
- HF06SilicaHouse grade
The silica lining we make most of. Repeat production for melt shops running the same job week after week.
- HF08SilicaSister to HF06
Sister grade to HF06 on the same silica base. Selected with us against your metal and working temperature.
- HF16SilicaOn application
Separate grade in the silica series. We confirm the fit against your application before you order.
Data sheet on request
- HF18SilicaMade to order
Made to order off the HF16 base. Content is set per order, so there is no fixed data sheet.
Data sheet on request
- HF12CRSilicaChrome grade
Chrome-bearing silica lining, produced to order against a confirmed application.
Data sheet on request
Alumina-based and andalusite-based dry-vibration linings for crucible induction furnaces melting steel and alloyed steel. Supplied dry, ready to use.
- Rodacor 86Alumina1 750 °C max
Alumina-based dry-vibration lining for induction crucible furnaces melting steel and steel alloys. Supplied dry, ready to use.
Variants · S · WF fine · WF coarse
- Rodamit 77Andalusite1 700 °C max
Andalusite-based dry-vibration lining for crucible induction furnaces melting alloyed steel. Supplied dry, ready to use.
Lines that go with the linings: a patching and repair compound we make, and a slag conditioner we bring in and repack. Data sheets on request.
- SP90AluminaPatch & repair
Super Patch 90. Alumina-based patch and repair compound. Supplied dry.
- SLXBought inSlag treatment
Slagbond. Slag conditioner, bought in and repacked by us.
Data sheet on request
From enquiry to first firing
How an order runs.
Tell us the furnace
Furnace size, the metal you melt, the grade you run now and what the lining is giving you.
Grade selected with you
We confirm the grade against your metal and working temperature, and quote straight.
Supply ex-Alberton
Mixed and checked at our own works. Collection ex-works, or delivery by arrangement.
Install talked through
Before the bags arrive we talk through the installation with the people doing it.
First firing on your floor
The sintered face forms during your start-up firing. We answer the phone when it matters.
Why foundries stay
The lining is the smallest line on a melt shop budget. Until it fails.
A lining failure stops the whole foundry. That is why our customers buy on spec and service, not price. We know the grades, we know the furnaces they go into, and we answer the phone.
- Manufacturer, not a reseller. HF series mixes are produced and checked at our own Alberton works.
- Decades of lining experience behind every grade recommendation.
- Specified into steel foundries, mineral processing OEMs and casting operations across South Africa.
- Collection ex-Alberton or delivery by arrangement.
Get a quote
Talk to us before the next reline.
Send us the furnace size, the grade you run now and what the lining is giving you. We quote quickly and we quote straight.
